| « Re: need advice 95 Q45 162k, gas smell (ahmed_wasim) | 8:10 PM 10/14/2006 |
|
The fuel hoses on the back side of the plenum are probably at fault.
The Infiniti Q45 Resource, Q45.org | Nissan VH series website NICO Sponsor Directory | Infiniti Of Scottsdale, 1-888-216-5328, ask for Joe, say Wes sent you.Need a Nissan/Infiniti Mechanic around Indy OR Northern Indiana?? EMAIL ME!!! BUY ESPELIR LOWERING SPRINGS FOR YOUR 90-01 Q45
|
CrimsonQ

Offline
1764 posts
Purple People Eater
Kansas Chitty KS
4-20-2005
|
Sounds like the same problem I had (posted a thread with video of hose dripping sometime last year)Was a 5-6 inch peice of hose running into firewall area under passenger side of plenum. Only leaked on cold starts then after soking in heat it would stop.
1st gen NICO ecu - 93 tcu -- Williams FSTB -- 2.75" SS exhaust -- 18" G35 wheels--255/45/18 -- President mirrors & trim -- SS Ultra
|
ahmed_wasim
Offline
144 posts
95 Q45
Toronto ON
9-2-2003
|
| « Re: (CrimsonQ) | 9:18 PM 10/14/2006 |
|
Hi, Do you still have the video. Or is it still posted somewhere Regards, Wasim.
|
Jesda

Offline
25639 posts
NICE
PANTS
5-5-2003
|
I just tightened mine. Its the vertical rubber hose with two metal clamps, right below the IAC. You -can- reach the screws with a small screwdriver if you move the throttle cables. Its a lot easier though to buy an IAC gasket and remove the IAC for cleaning while youre back there.
ALL NEW FACEPALM EMOTICON! USE IT!BUY INFINITI PARTS - 1-888-216-5328 | NICO Porn Thread | http://www.q45.org | http://www.vh45de.com
|
ahmed_wasim
Offline
144 posts
95 Q45
Toronto ON
9-2-2003
|
| « Re: (ahmed_wasim) | 8:42 AM 10/15/2006 |
|
The link from last yearhttp://www.sdproducktions.biz/media/qfuelvid.mov no longer works
|
CrimsonQ

Offline
1764 posts
Purple People Eater
Kansas Chitty KS
4-20-2005
|
ahh i need to pay my bill lol. Itll be back up tonight 8pm central.I tightened mine as well but later replaced
|
ahmed_wasim
Offline
144 posts
95 Q45
Toronto ON
9-2-2003
|
| « Re: (CrimsonQ) | 7:11 PM 10/15/2006 |
|
Hi,I tightened mine also. It was a small vertical one in the area shown in the picture. I was only able to tighten the bottom part of hose. There is no way to reach the upper part. I didn't try to tighten it too much, just 3-4 rotations, is that enough or should I tighten it more. I drove the car after that, initially there was some smell but now it seems gone. I'll try again. Regards, Wasim.
Attachment: hose.jpg (98669 bytes, downloaded 1527 times)

|
goody94q45
Q45 Undertaker

Offline
1745 posts
94Q45 Gray/Gray
Orangevale CA
8-17-2005
|
| « Re: (ahmed_wasim) | 7:27 PM 10/15/2006 |
|
That's the spot they were directing you to. I had two leakers back there when I first bought my Q and eventually was able to get to them both. I gave up at first but kept going back with different tools. With the right tools you can get to the clamps you've given up on. Make sure to check for leaks with the engine cold as small leaks tend to slow down as the hoses heat and expand. As Jesda suggested, you may have to remove the IAC valve (adjacent to the right side of your circle) to get to all the clamps. Hopefully you've reached and tightened the right clamp(s) and the fuel odor will go away once the residual evaporates. Good luck.
Mike "Goody" Goodwin 94 Q45 157,000 miles ____________________ 90 Q45 115,000 miles (The Beauty) ___________________________ (The Beast)

|
lino

Offline
1505 posts
1991 Q45 ACTIVE
Canada
8-15-2005
|
| « Re: (ahmed_wasim) | 2:46 PM 11/7/2006 |
|
Are these the hoses you guys are referring to?


Can anyone tell if these look original or if they may have been replaced? I checked mine and they are very tight. I get the fuel smeel in the morning when I start the car for the first time.
Registered ®
 Need ACTIVE Suspension Parts or Have Questions: http://www.activesuspensionsystems.com/index.html http://www.q45asuspension.com/
|
96Qowner
Moderator

Offline
2150 posts
1996 Q45
Fargo ND
9-7-2004
|
| « Re: (lino) | 2:59 PM 11/7/2006 |
|
Those aren't the ones. The usual suspect is a fuel hose buried deep under the middle of the plenum. It connects to the fuel pressure regulator and leads to the hard line to the fuel filter. Kinda under that yellow rectangle in the previous pics.
1996 Q45 -210,000 miles 1990 Accord - 394,000 1966 Thunderbird Q code - 87,000
|
lino

Offline
1505 posts
1991 Q45 ACTIVE
Canada
8-15-2005
|
| « Re: (96Qowner) | 3:01 PM 11/7/2006 |
|
Thanks I'll try to locate it tomorrow morning.
|
GeesQ
Offline
4 posts
1994 Q45
Los Angeles CA
8-3-2006
|
| « Re: (lino) | 2:12 PM 11/21/2006 |
|
I had the same problem with my 94 Q and this morning I tightened those hoses and it seemed to have done the trick. The screws were amazingly loose where I was able to turn one about 4 times and the second one about 3.
|
lino

Offline
1505 posts
1991 Q45 ACTIVE
Canada
8-15-2005
|
| « Re: (GeesQ) | 4:26 PM 11/21/2006 |
|
Anyone have any pics?
|
Q45tech
Q45 Guru
Online
11937 posts
1990 Q45 319,000 miles
Marietta , Georgia
4-30-2002
|
| « Re: (lino) | 4:41 PM 11/21/2006 |
|
Modern fuels eat these hoses from the inside and thus their I.D. increases.Tightening once is just a temporary fix. Just part of the PERIODIC [every] 80-120k under plenum hose replacement.
