How to: Newspaper Pull

The Nissan 300ZX (Z32) general community discussion forum
User avatar
ArticDragon192
Posts: 2767
Joined: Fri Sep 10, 2004 5:35 pm
Car: 91 Z32 2+2

Post

Before I begin, let me make this very clear.
Your fenders must be rolled FLAT already
If they aren't rolled, the pull isn't going to work.
If the roll isn't completely flat, the pull won't come out evenly and flawless.

Now, with that said, here we go.

So, you all know, I have a new car. Meaning, new fenders to play with. Obviously my old wheel set up wasn't going to work with the barely modded fenders the car came with. It worked before, but I was running more than -4* of camber. I recently got an alignment and opted to run -3* all around (driving style preference, I'm not trying to conserve tires here, lol)
Less camber meant my tires were going to rub, so I had to pull my fenders. As always, I turn for the newspaper method of pulling fenders for the clean, flat pull that is barely noticeable. Please note, I am NOT using newspaper, but a comparable paper. What is key is that the paper you pick can easily slide. A magazine or book will not work well since the bindings will prevent the pages from sliding freely. As always, newspaper is the best thing you can use.
I used the next best thing.... paper car mats, lol

First of all, you're going to want to jack up the rear by the tow hook, and remove he rear wheel. The you're going to want to disconnect the lower mount of the rear shock.

Remove the nut and bolt, and swing the lower mount out of the way.

Make sure the lower mount is clear of everything. You do not want it to catch on anything.

With the car in the air, and the wheel at full droop, this is what it looks like:
Not too bad, but remember it will camber in a bit, like so:
The fender just catches the tire, so rubbing will occur.

Next, you're going to want to heat up the fender, from where I'm point at, and to the right. Use either a heat gun, or if you're brave, a propane torch, lol

You want to hit the fender from the bottom and up, to heat up the lip of the fender on both sides.

Next, grab about less than a thumb's width of newspaper for the initial treatment.
Again, I'm using mechanic's paper floor mats. It works just as well.

With the fender heated, stuff the newspaper into the wheel arch, between the fender and tire. Make sure to have the newspaper span the whole area you heated up, or else you'll pull one section more than the other.

Then you're going to drop the car slowly, until the tire touches the floor, and the wheel begins to tuck itself inside the fender.

Now, it will make some noise it is just the sound of the fender sliding over the newspaper. Let it sit for couple of minutes, to give the fender time to cool off and take shape. You're going to want to then raise the car and remove the paper. Drop it back down to where you're tucking tire, like so:

You're going to want to check for rubbing issues. What I do is take some thin paper, and slide it between the tire and fender:

If the paper snags, then you still need to pull more. The tire was touching the fender in the area between where the paper is placers in the two pics.
Again, heat up the fender, and grab more paper.

Rinse and repeat as needed.

You can see the fender slowly taking a flat flared look

Just as a warning, the driver side fender will require more effort to pull, due to the gas cap there reinforcing the fender. So don't freak out if you need significantly more newspaper on the driver side than on the passenger side.

Keep repeating the process by adding a slight amount more newspaper at every pass. My passenger side took 2 passes. Driver side took 4. Again, this is normal. And here are the results:

Hope this helps everyone.


User avatar
audtatious
Moderator
Posts: 25014
Joined: Sun Oct 27, 2002 5:31 pm
Car: 2017 Q60 Red Sport. Gone: 2014 Q50s, 2008 G37s coupe, 2007 G35s Sedan, 2002 Maxima SE, 2000 Villager Estate (Quest), 1998 Quest, 1996 Sentra GXE
Location: Stalking You
Contact:

Post

Do you have another location to host the pix?

User avatar
nuttin but Z32
Posts: 211
Joined: Thu Jun 17, 2010 5:11 pm
Car: 1991 300zx 2+0.
Location: tampa,Florida

Post

audtatious wrote:Do you have another location to host the pix?
I know right pics aren't showing =S

User avatar
300ZXttZMAN
Posts: 6800
Joined: Mon Nov 22, 2010 4:07 pm
Car: 1990 Nissan 300ZX TT 5spd pearl white

DD: 2008 Nissan Frontier NISMO pkg 4x4 Crew Cab
Location: Sulphur, LA 70665
Contact:

Post

Yea cant see pics. :(

User avatar
DCaff300ZX
Posts: 4202
Joined: Sun Jun 14, 2009 8:18 am
Car: .
1993 CRP TT- Modified
Location: Tacoma, Washington

Post

Very interesting.
Thanks for sharing Edgar!

User avatar
300ZXttZMAN
Posts: 6800
Joined: Mon Nov 22, 2010 4:07 pm
Car: 1990 Nissan 300ZX TT 5spd pearl white

DD: 2008 Nissan Frontier NISMO pkg 4x4 Crew Cab
Location: Sulphur, LA 70665
Contact:

Post

Great write up...

SAVED in favorites!

EDIT: :dblthumb:

User avatar
simmode1
Posts: 7918
Joined: Fri Aug 17, 2007 4:51 pm
Car: Red '95 S14
Location: Euless, TX
Contact:

Post


User avatar
300ZXttZMAN
Posts: 6800
Joined: Mon Nov 22, 2010 4:07 pm
Car: 1990 Nissan 300ZX TT 5spd pearl white

DD: 2008 Nissan Frontier NISMO pkg 4x4 Crew Cab
Location: Sulphur, LA 70665
Contact:

Post

simmode1 wrote:Image

:rotflmao

AllGoNShow
Posts: 20
Joined: Thu Jul 14, 2011 11:20 pm
Car: '95 TT T-Top
Black on Black
Location: Calgary, Canada

Post

Perfect write up on it, thanks!

User avatar
whiteknight52
Posts: 87
Joined: Thu Aug 26, 2010 2:18 am
Car: 1990 300zx NA 5spd
Location: Scio, OR

Post

Very cool right up!! Thanks for the info man!
