FITMENT DATABASE - Post your wheel setup! (no pics with specs = deleted)

[Spider]

- Drag DR-20
- Diameter: 15
- Width: 7
- Offsets: 0
- Does NOT clear Z brakes.
- Suspension: stock
- No fender mods.
- Tire Size: 205/60/15

[w8lifter21]

MSR 088
19x8 +25 offset 245/35/19
19x10 +40 offset 285/30/19
Stock suspension, no rub. Yes I know I need to lower it a bit, sorry for the crappy phone pic, will try and get better ones up soon

[vr446]

Probably been done, but here's my contribution..sorry not that aggressive
F: 17x8 +25mm (235/45/17)
R: 17x9 +35mm (255/40/17)
Zeal Coilovers, ENDLESS 6-POT front and Z32 Calipers rear
Front no spacer, Rear 10mm HR spacer
Rolled and pulled rears only, front fits no prob, but if car sits too low it will rub fender liner and wire harness on drvr side

[iseenem240SX]

OEM 350Z Touring V.1
- 18" diameter
- 8" wide Front/Rear
- +30 mm offset Front/Rear
- No idea on Z brakes, looks like there's lots of room for them though.
- KYB GR2's and stock springs. (Coilovers soon).
- No roll.
- 225/45/18 Front and 245/45/18 Rear










Modified by iseenem240SX at 8:15 PM 4/27/2009

[Skilz10179]

- Rota P45R
- Front - 17x9 +25 245/40/17
- Rear - 17x9.5 +30 275/40/17
- Offsets
- Stock brakes for now
- Stance GR+Pro Coilovers
- Fenders rolled

[matzinm2]

Does anyone have ROTA RB's on their hatch? I'd like to see that... thinkin bout em.

[drifter92]

Stock Zenki Base Wheels
Front - 15"x6.5" +42 195/60/15
Rear - 15"x6.5" +42 195/60/15
1" Spacers All Around
Stock Brake Size
Godspeed Coilovers
Rolled Fenders, Slight Pull In Rear(Not Necessary)

[truckskinjoe]

Here are a few pics of our 90 S13 with an RB 26 DETT AWD swap, tires are Michelins P285 x 35, 18s on Rota P45 Rs 9.5" with +20 offset. No lowering yet, stock suspension / well sort of anyway, it has the S13 struts, but a 350 rear assembly and the Skyline front hubs and knuckles. Anyway here are the pics. Oh yes I drive it daily. race some on weekends.

[drifter92]

Nippon F1 Wheels
Front - 17"x7" +40 225/45/17
Rear - 17"x7" +40 225/45/17
1" Spacers all around
Stock Brake Size
Godspeed Coilovers(Don't go low enough)
Rolled Fenders, Slight Pull In rear(Not necessary for these wheels)

[usdm_180sx]

Are you f**king serious??? Get that s*** outta here!!!



17x9 +16 215/40-1717x10 +18 235/40-17

Federal 595

[E7-S14]

- XXR/Sportmax 006
- 19x8.5/F 19x9.5/R
- +5/F +10/R *with 25 and 30mm spacers*
- Clears Z brakes with coilovers (should clear without)
- Coilovers
- Roll and Pull Front and Rear
- 235/35/19(F) 245/35/19(R)

-(If wanting to go low) Requires Front Inner Fender Wells to be Modified ( aka Beat the F* in) and wire tuck.

[boriquaS13]

Work meister s1
17X9+2 (with 10mm spacer)
17x10-5 (with 20mm spacer)
215/40 front
235/40 rear
clears z32 brakes no problem
stance coils and all suspension arms
-3 degrees camber front
-3 degrees camber rear

[Kalypso]

^ NICE

[boriquaS13]

^Thanks Kalypso

[blacktop sr20kid]

- Wheel Brand- rota p45r's
- Diameter- 17
- Width- 9.5
- Offsets- +12
- Does it clear z brakes and coilovers- i dont have z brakes, i have q45.
i do have ksport coils and it clears them just fine.
- Suspension modifications- koils. toe arms ruca's tension rods and tierods are all adj. ones
-What fender modifications- i did a slight roll in the front and the back was a little more of a roll. also folded the the inner seem in the front fender tucked my harness.
- Tire Sizes- 225/45 front 245/45 rear






and my last s13



17x9+10 all around 205/45 F and 225/45 R



Modified by blacktop sr20kid at 7:28 PM 3/14/2010

[pauliedrft]

rims xxr 962 17x9 fr& rr +35 rear & + 25 front with 10mm spacers
stock suspension with lowering springs 1.5 and 2.0
235/40 /17 fronts
clears z32 brakes
275/40/17 rear slight pull and rolled
20mm over fenders in front .






Modified by pauliedrft at 11:52 AM 4/7/2010

[SwaggaJackaS14]

Them rare a** Elites yo

17x9 +15

245/45zr17s all the way around

rolled fenders and quarters

[slidestyle69]

your s14 is clean man, i like those elites. let me ask you something...you like mudkip?

[mrdicks95se]

VMR VB3
18x8.5 +15 effective
18x9.5 +20 effective
225/35 Fr
255/35 Rr
25mm spacer adapter conversion 5x114.3 to 5x120
Koni Yellow/GC
No Camber/toe adjustments (zero'd out)
Clears Z32 BBK and 13.1" Rotors
Rear fender roll

[Broadfield]

- Wheel Brand: Work Meister S1-3P.
- Diameter: 18".
- Width: Front 9.5" and Rear 11".
- Offsets: Front +12 and Rear +30.
- Does it clear z brakes and coilovers: Yes, clears Z and BBK's.
- Suspension modifications/coilovers/springs and struts: Front -3.25 degrees of camber and rear -2.5 degrees of camber. Stance RUCA's and Stance GR+ coilovers.
- Are there any fender modifications?: Front +20 ChargeSpeed fenders and Rear +25mm pull.
- Tire Sizes: Front 245/35 and Rear 285/30.
- Any other relevant info: For the rear had to notch the lower control arm around a 1/4" and hammer the crap out of the upper inner wheel well housing.

[nismoracingsx]

1. Sportmax 521 Bronze w/ chrome lip.
2. 16x8 front and rear
3. +20 front and rear.
4. No idea on coilovers/z32 brakes as I don't have either.
5. Skunk2 coils on agx's. RUCAs.
6. Stock fenders
7. 205/50r16

[The Bodyguard]

2008 Infiniti M45 Sport
Wheels: Versante 219
size: 22"x8.5" all around
offset: +40 all around
Tires 245/30/22" all around
CAN I FIT AND DO AN EIBACH PRO KIT DROP(1.6" FRONT 1.0 REAR) and how bad is the camber kit needed? A few shops are telling me almost no one does the camber kits...??

[riggz]

2008 Infiniti M45 Sport
Wheels: Versante 219
size: 22"x8.5" all around
offset: +45 all around
Tires 245/30/22" all around
CAN I FIT AND DO AN EIBACH PRO KIT DROP(1.6" FRONT 1.0 REAR) and how bad is the camber kit needed? A few shops are telling me almost no one does the camber kits...??

I like those rims. Did you have them painted?

[The Bodyguard]

Rims came like you see them. I like the black lip with the machined look....too much chrome for me in the past!! Here's a side shot!

[KAmakazi]

- Wheel Brand: Rota P45R
- Diameter: 17
- Width: 9
- Offsets: +12
- Not positive on the Z brakes, but pretty sure lol
- Suspension modifications: Meagan Streets
- Rear Fenders Rolled, Fronts stock-
235/45/17-Front
245/40/17-Rear





I love the fitment. Hopefully its worthy

[Ryen20till3]

xxr 002 chromium black
16
8
+0 offset
no to z brakes
dmax coilovers
rolled F/R fenders
195/50/16 slight strech

[stanceboss]

hi guys



i am runing volk te37's 17 x 8.5 with +10 ofset, my car is SO COOL

i have tein lowring springs but they are 2 hi for me i am looking for cheep TOCKICO ones if anyone has them my cell num is 412-867-5309 call and aks for daniel

[potatosparkles]

my car sucks



15x8 effectively -38 with
15x10 -50
Falken ZE512 205/50-15

[stanceboss]

my car sucks



15x8 effectively -38 with
15x10 -50
Falken ZE512 205/50-15

hey those stickurs are kool wqnt to send me a few ill pm you my addres

also is ther a side pic of ur car i wanna see it

[potatosparkles]

no stickers for you

also:
-2.5* camber up front
-5.5* camber out back
custom Koni/sleeve coilover up front with 10k springs
Megan S13 street rear coilovers with 10k springs (going to upgrade to track dampers and run 12k springs)
